Moyan Electromechanical Antistatic Agent External Coating System

1、This product is a powerful intelligent control system for yarn winding and oiling. It realizes the linkage between the yarn winding machine and the intelligent yarn creel, and supports automatic stop functions for yarn breakage, yarn tangling, yarn fluffing and residual yarn.

2、High-precision oiling with an error of less than ±2%, and the oiling rate ranges from 20 to 200 drops per minute.

3、Customizable parameters: oiling parameters can be set freely, and the speed mode and droplet mode are switchable. It supports oiling for raw yarn doubling of various Tex specifications.

4、User-friendly human-machine interface (HMI) with excellent compatibility and stability, enabling intelligent, stable and high-precision control.

5、The control system adopts PLC programming control and is equipped with a 10-inch large touch screen for easy operation and a friendly human-machine interface.

6、The independently developed droplet monitoring system uses an infrared monitoring device to count droplets, featuring superior anti-interference performance and high-precision signal output. It sets the oiling volume, controls the linkage between the peristaltic pump and the yarn winding machine, and realizes proportional control.

7、The equipment is made of stainless steel and driven by safe voltage.

8、Equipped with an automatic lifting device: the yarn is lifted and separated from the oiling tank when the yarn winding machine stops.

9、Function expansion: integrates instrument control, method management, data analysis, standard curve generation, report editing, user authority management, audit trail, digital signature and network database functions.

10、Equipped with data statistics, software analysis and data output functions, meeting the requirements of data traceability and data security.

11、Intelligent management and identification functions: combined with the image recognition system, it realizes automatic stop for yarn tangling, residual yarn and yarn fluffing.
